NX-CT2120
NX-CT2120; High-speed counter unit ideal for edge control, achieving high-speed response and high-resolution performance (Channnels 2(NPN), Max response frequency 1 MHz, 5 V/24 V voltage input)
2026 Liste Fiyatı;
656,50€
| I/O system | NX I/O Bus |
|---|---|
| Type of module | Encoder input |
| Digital input type | Incremental encoder, NPN, Voltage pulse |
| Digital output type | NPN, PWM |
| Signal processing | Free running, Synchronous, Task period prioritized |
| Number of encoder input channels | 2 |
| Max. encoder input frequency | 1000 kHz |
| Number of pulse input channels | 6 |
| Number of pulse output channels | 1 |
| Max. pulse output frequency | 0 kHz |
| IO-Link master | No |
| I/O connection type | Push-in |
| Number of I/O connectors | 6 |
| Detachable I/O terminal block | Yes |
| Suitable for safety functions | No |
| SIL according to IEC 61508 | None |
| Number of IOV (V+) terminals | 0 |
| Number of IOG (V-) terminals | 2 |
| Number of COM terminals | 0 |
| Degree of protection (IP) | IP20 |
| Product Weight (unpacked) | 0 g |
